Based on 0.98" DLP Cinema technology, the Christie CP2215 uses high efficiency, long lasting CDXL-SD series Xenon lamps as well as the CDXL-14M and CDXL-16M, new lamps designed for long life and low power consumption. The competition requires higher wattage lamps for the same light output, giving Christie clear advantage on cost of ownership and lumens per watt. A robust and reliable addition, the Christie CP2215 features a motorized lensing solution and a selection of eight zoom lenses to guarantee the right lens solution for virtually any auditorium with no need for resizing or scaling. It is the projector of choice for small screens and post production applications that demand performance and reliability in a small, affordable package. Christie CP2215 127-010102-01 Including Christie Previsto™ High Frame Rate (HFR) technology, your investment is ready for the next evolution of digital cinema. Display premium 2D/3D HFR feature film and alternative content in its original format, giving your audiences the best visual experience possible 2K, Series 2 DLP Cinema technology DCI compliant 3D ready Lowest cost of ownership Accessories – for easy integration into any environment, Christie’s full range of digital cinema accessories includes the Christie Integrated Media Block (IMB), the Christie Cine-IPM 2K for alternative content, the Christie SKA-3D for economical Audio/Video processing, the Christie ACT automation control system, and a full suite of lenses and lamps Standard support for HDCP and SNMP Split power operation for use with UPS Local control via flexible Touch Panel Controller (TPC) and full access from anywhere via web based GUI One-piece compact design for flexible mounting and installation Rear access for quick and easy lamp changes Intelligent Lens System (ILS™), custom designed for cinema, for reliable motorized lens operation In its standard configuration, the Christie CP2215 requires no heat extraction, an optional duct is available if desired Dual HD-SDI connectors for continued compatibility with 2K cinema servers
Specifications CP2215 Brightness1 lamp • 1.4kW (CDXL-14M) 003-003066-01 • 1.6kW (CDXL-16M) 003-003900-01 • 1.8kW (CDXL-18SD) 003-002742-01 • 2.0kW (CDXL-20SD) 003-001976-01 • 2.3kW (CDXL-23S) 003-004769-01 nominal range • 2900 -15,000 lumens screen size • 50' screen1 Supported frame rates • 2D up to 120 fps, 3D up to 60 fps/eye2 Contrast ratio • 2000:1 full field on/off Digital micromirror device • 0.98" 2K 3-chip DMD DLP Cinema • 2048 x 1080 pixels Input line voltage • Single phase 220V Number of colors • 35.2 trillion Lenses • See christiedigital.com Power supply • 0.7kW-2.3kW low-ripple switch mode lamp power supply Standard inputs • 2 x HD-SDI inputs for 2K source content • 2 x DVI (HDMI) inputs for alternative content Weight • As installed: 122lbs (55kg)
